Lenovo ThinkSystem SR650 V2 2U Rack Server
The Lenovo ThinkSystem SR650 V2 is a 2-socket, 2U rack server engineered for high-performance workloads including databases, virtualization, and cloud computing. Powered by 3rd Generation Intel Xeon Scalable processors, it delivers extensive scalability for storage and memory requirements.
Key Technical Specifications
- Processors: Supports up to two 3rd Gen Intel Xeon Scalable processors with up to 40 cores per socket and maximum TDP of 270W
- Memory: 32 DIMM slots supporting up to 8 TB using 256 GB 3DS RDIMMs, compatible with Intel Optane Persistent Memory 200 Series for total capacity up to 12 TB
- Storage Flexibility: Up to 40x 2.5-inch or 20x 3.5-inch drive bays with NVMe, SAS, and SATA support including AnyBay technology
- Expansion & GPU: Up to 8x PCIe 4.0 slots and one OCP 3.0 slot, supporting up to 3 double-wide or 8 single-wide GPUs for AI and machine learning
- Management: Lenovo XClarity Controller for simplified system management with ThinkShield suite for end-to-end security
Typical Workloads
The server's balanced architecture is optimized for:
- Hybrid Cloud: Validated designs for seamless integration
- VDI & Enterprise Apps: High core counts and GPU support for virtual desktop infrastructure
- Big Data & Analytics: Low-latency storage and large memory capacity for real-time insights
Server Comparison: SR650 V2 vs Competitors
| Item |
Lenovo SR650 V2 |
Dell PowerEdge R650 |
HPE DL380 Gen10 Plus |
| Form Factor |
2U |
1U |
2U |
| CPU Generation |
3rd Gen Xeon |
3rd Gen Xeon |
3rd Gen Xeon |
| Max CPU |
2 * CPU |
2 * CPU |
2 * CPU |
| Max Cores |
Up to 40 cores |
Up to 40 cores |
Up to 40 cores |
| Memory Type |
DDR4 |
DDR4 |
DDR4 |
| Memory Slots |
32 DIMMs |
32 DIMMs |
32 DIMMs |
| Max Memory |
Up to 4TB |
Up to 4TB |
Up to 4TB |
| Memory Speed |
3200 MT/s |
3200 MT/s |
3200 MT/s |
| Storage Bays |
Up to 40 * 2.5" |
Up to 10 * 2.5" |
Up to 24 * 2.5" |
| NVMe Support |
Up to 24 NVMe |
Up to 12 NVMe |
Up to 20 NVMe |
| PCIe Version |
Gen4 |
Gen4 |
Gen4 |
| GPU Support |
Strong |
Limited |
Moderate |
| Power Supply |
Up to 1800W |
Up to 1100W |
Up to 1600W |
| Management |
XClarity |
iDRAC9 |
iLO 5 |
| Best Use Case |
Storage / Virtualization |
Compute / Density |
Enterprise IT |
| Positioning |
High expansion |
High density |
Balanced |
Detailed Technical Specifications
| Item |
Specification |
| Model |
Lenovo ThinkSystem SR650 V2 |
| Form Factor |
2U Rack Server |
| Processor |
1–2 * 3rd Gen Intel Xeon Scalable (Ice Lake) |
| Max CPU Cores |
Up to 40 cores per CPU |
| Socket |
LGA 4189 |
| Chipset |
Intel Platform |
| Memory Type |
DDR4 RDIMM / LRDIMM |
| Memory Slots |
32 DIMM Slots |
| Max Memory |
Up to 4TB |
| Memory Speed |
Up to 3200 MT/s |
| Persistent Memory |
Intel Optane PMem 200 Series supported |
| Storage Options |
SAS / SATA / NVMe |
| Drive Bays |
Up to 40 * 2.5" or 20 * 3.5" |
| NVMe Support |
Up to 24 NVMe SSD |
| Boot Options |
M.2 SSD / Rear boot drives |
| RAID Controller |
ThinkSystem RAID 930 / 940 Series |
| Network |
OCP 3.0 NIC (1/10/25Gb) |
| Expansion Slots |
Up to 8 * PCIe Gen4 |
| GPU Support |
Up to 7 single-width or 3 double-width GPUs |
| Power Supply |
750W / 1100W / 1600W / 1800W (Redundant) |
| Cooling |
Air cooling with hot-swap fans |
| Management |
Lenovo XClarity Controller |
| Security |
Trusted Platform Module (TPM 2.0), Secure Boot |
| Operating System |
Windows Server / Linux / VMware |
| Dimensions (H*W*D) |
86.5 * 445 * 782 mm |
