Lenovo ThinkSystem SR630 V3 1U Rack Server with 5th Gen Intel Xeon Scalable Processors, 32x DDR5 DIMMs, and 16x EDSFF E1.S Drives

Product Categories
Ideal Future (beijing) Information Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Lenovo ThinkSystem SR630 V3 1U Rack Server with 5th Gen Intel Xeon Scalable Processors, 32x DDR5 DIMMs, and 16x EDSFF E1.S Drives

RAM : Supports up to 32x TruDDR5 3DS/RDIMMs

Delivery Time : around 15days

processor : Up to 2x 5th Gen Intel Xeon Scalable processors, up to 64 cores and 385W TDP

Place of Origin : China

From Factor : 1U rack server

Network : LOM adapter installed in the OCP 3.0 slot, optional for front access Networking PCIe adapters

MOQ : 1

Price : USD 2,250/pcs

Payment Terms : T/T,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;

Supply Ability : Quantity (pieces) 1-10 for around 15days, > 10, to be negotiated

Brand Name : Lenovo

Model Number : SR630 V3

Packaging Details : Carton with waterproof warpped

Drive Bays : Up to 4x 3.5” or 12x 2.5” or 16x EDSFF E1.S drives Front: up to 4x 3.5” / 10x 2.5” /16x EDSFF E1.short hot swap drives Rear: 2x 2.5”; 7mm SATA/NVMe hot-swap boot drives, support RAID Internal 2x M.2 SATA/NVMe boot drives, support RAID Direct NVMe, VROC/VMD

Contact Now

Lenovo ThinkSystem SR630 V3 1U Rack Server
Lenovo ThinkSystem SR630 V3 1U Rack Server with 5th Gen Intel Xeon Scalable Processors, 32x DDR5 DIMMs, and 16x EDSFF E1.S Drives Lenovo ThinkSystem SR630 V3 1U Rack Server with 5th Gen Intel Xeon Scalable Processors, 32x DDR5 DIMMs, and 16x EDSFF E1.S Drives Lenovo ThinkSystem SR630 V3 1U Rack Server with 5th Gen Intel Xeon Scalable Processors, 32x DDR5 DIMMs, and 16x EDSFF E1.S Drives Lenovo ThinkSystem SR630 V3 1U Rack Server with 5th Gen Intel Xeon Scalable Processors, 32x DDR5 DIMMs, and 16x EDSFF E1.S Drives Lenovo ThinkSystem SR630 V3 1U Rack Server with 5th Gen Intel Xeon Scalable Processors, 32x DDR5 DIMMs, and 16x EDSFF E1.S Drives
Technical Specifications
Form Factor/Height 1U rack server
Processor Up to 2x 5th Gen Intel Xeon Scalable processors, up to 64 cores and 385W TDP
Drive Bays
  • Up to 4x 3.5" or 12x 2.5" or 16x EDSFF E1.S drives
  • Front: up to 4x 3.5" / 10x 2.5" / 16x EDSFF E1.short hot swap drives
  • Rear: 2x 2.5"; 7mm SATA/NVMe hot-swap boot drives, support RAID
  • Internal 2x M.2 SATA/NVMe boot drives, support RAID
  • Direct NVMe, VROC/VMD, and onboard SATA with SW RAID (0,1,5,10)
Memory Supports up to 32x TruDDR5 3DS/RDIMMs
Expansion Slots Up to 5x PCIe 4.0/5.0 slots, 1x OCP 3.0 slot, 1x cabled internal HBA/RAID adapter that doesn't occupy a standard PCIe slot
GPUs Up to 3x single-width 75W GPUs
Network Interface LOM adapter installed in the OCP 3.0 slot, optional for front access Networking PCIe adapters
Ports
Front:
1x USB 3.2 G1, 1x USB 2.0 for BMC, 1x VGA (optional), 1x external diagnostics handset port (optional)
Rear:
3x USB 3.2 G1, 1x VGA, 1x 1GbE RJ45 (management), 2nd 1GbE management port (optional in OCP slot location), and 1x Serial port (optional)
Internal:
1x USB 3.2 G1 and MicroSD card port
HBA/RAID Support SATA with SW RAID (0,1,5,10); Common building blocks including standard and Internal PCIe RAID/HBA adapters
Power Dual Redundant AC & DC; Platinum & Titanium; 750W, 1100W, 1800W, and 1100W -48V DC Platinum
Systems Management Lenovo XClarity Controller
OSes Supported Microsoft, SUSE, Red Hat, VMware

Product Tags:

5th Gen Intel Xeon Scalable processors Rack Server



32x DDR5 DIMMs 1U Server



16x EDSFF E1.S drives Lenovo ThinkSystem SR630 V3
